Trend plot

Source: R/trendplot.R
TrendPlot.Rd

A trend plot is like an area plot but with gaps between the bars.

Usage

TrendPlot(
  data,
  x,
  y = NULL,
  x_sep = "_",
  split_by = NULL,
  split_by_sep = "_",
  group_by = NULL,
  group_by_sep = "_",
  group_name = NULL,
  scale_y = FALSE,
  theme = "theme_this",
  theme_args = list(),
  palette = "Paired",
  palcolor = NULL,
  alpha = 1,
  facet_by = NULL,
  facet_scales = "fixed",
  facet_ncol = NULL,
  facet_nrow = NULL,
  facet_byrow = TRUE,
  x_text_angle = 0,
  aspect.ratio = 1,
  legend.position = waiver(),
  legend.direction = "vertical",
  title = NULL,
  subtitle = NULL,
  xlab = NULL,
  ylab = NULL,
  seed = 8525,
  combine = TRUE,
  nrow = NULL,
  ncol = NULL,
  byrow = TRUE,
  ...
)

Arguments

data

A data frame.

x

A character string specifying the column name of the data frame to plot for the x-axis.

y

A character string specifying the column name of the data frame to plot for the y-axis.

x_sep

A character string to concatenate the columns in x, if multiple columns are provided.

split_by

The column(s) to split data by and plot separately.

split_by_sep

The separator for multiple split_by columns. See split_by

group_by

Columns to group the data for plotting For those plotting functions that do not support multiple groups, They will be concatenated into one column, using group_by_sep as the separator

group_by_sep

The separator for multiple group_by columns. See group_by

group_name

A character string to name the legend of fill.

scale_y

A logical value to scale the y-axis by the total number in each x-axis group.

theme

A character string or a theme class (i.e. ggplot2::theme_classic) specifying the theme to use. Default is "theme_this".

theme_args

A list of arguments to pass to the theme function.

palette

A character string specifying the palette to use. A named list or vector can be used to specify the palettes for different split_by values.

palcolor

A character string specifying the color to use in the palette. A named list can be used to specify the colors for different split_by values. If some values are missing, the values from the palette will be used (palcolor will be NULL for those values).

alpha

A numeric value specifying the transparency of the plot.

facet_by

A character string specifying the column name of the data frame to facet the plot. Otherwise, the data will be split by split_by and generate multiple plots and combine them into one using patchwork::wrap_plots

facet_scales

Whether to scale the axes of facets. Default is "fixed" Other options are "free", "free_x", "free_y". See ggplot2::facet_wrap

facet_ncol

A numeric value specifying the number of columns in the facet. When facet_by is a single column and facet_wrap is used.

facet_nrow

A numeric value specifying the number of rows in the facet. When facet_by is a single column and facet_wrap is used.

facet_byrow

A logical value indicating whether to fill the plots by row. Default is TRUE.

x_text_angle

A numeric value specifying the angle of the x-axis text.

aspect.ratio

A numeric value specifying the aspect ratio of the plot.

legend.position

A character string specifying the position of the legend. if waiver(), for single groups, the legend will be "none", otherwise "right".

legend.direction

A character string specifying the direction of the legend.

title

A character string specifying the title of the plot. A function can be used to generate the title based on the default title. This is useful when split_by is used and the title needs to be dynamic.

subtitle

A character string specifying the subtitle of the plot.

xlab

A character string specifying the x-axis label.

ylab

A character string specifying the y-axis label.

seed

The random seed to use. Default is 8525.

combine

Whether to combine the plots into one when facet is FALSE. Default is TRUE.

nrow

A numeric value specifying the number of rows in the facet.

ncol

A numeric value specifying the number of columns in the facet.

byrow

A logical value indicating whether to fill the plots by row.

...

Additional arguments.

Value

A ggplot object or wrap_plots object or a list of ggplot objects

See also

AreaPlot

Examples

data <- data.frame(
    x = rep(c("A", "B", "C", "D"), 2),
    y = c(1, 3, 6, 4, 2, 5, 7, 8),
    group = rep(c("F1", "F2"), each = 4)
)
TrendPlot(data, x = "x", y = "y", group_by = "group")

TrendPlot(data, x = "x", y = "y", group_by = "group",
         scale_y = TRUE)

TrendPlot(data, x = "x", y = "y", split_by = "group")

TrendPlot(data, x = "x", y = "y", split_by = "group",
          palette = c(F1 = "Set1", F2 = "Paired"))
